HDPE Pipes & Coils SNC
Product Brief
- HSN Code : Pipes- 39172190
- Material: High Density Poly Ethylene (HDPE) Grade – PE 63, PE80 & PE100
- Pressure Rating: PN 2.5, 4, 6, 8, 10, 12.5, 16, 20
- Size: 16 mm to 450 mm
- Standard: IS 4984 : 2016 HDPE SNC IS 14333 : 1996
- Colour: Black
- Form Supplied: HDPE Pipe in Various PN class and Sizes in Tube as well as Coil.
HDPE Pipes & Coils SNC
HDPE Pipes & Coils SNC
uPVC Casing Fittings
uPVC Casing Moulded Fittings
End Cap Threaded
More DetailsuPVC Casing Fabricated Fittings
Advantages
Strength and Durability
Corrosion Resistance
Flexibility
Long Service Life
Leak-Free Joints
Ease to Installation
Recyclability
Eco Friendly
Technical Details
Considerations
- Above information is given for guidance. It is subject to pump performance and allied conditions including pipe selected.
- It is a free discharge at well head at residual head of 3m (0.3 kg/cm²).However, if users want to take it further, then additional parameters- static head, friction losses need to be accounted for while selecting piping system.
- Table 1.3 Max permissible pump head indicated is inclusive of static head, frictional head losses in pipe line & fittings.
- Depth of coil installation has been worked out by accounting pump / cable / pipe weight, water column & water hammer.
- Discharge calculated above is based on assumed water velocity of 1.6 +/- 0.1 m/sec through the pipe.
- Once depth of installation of submersible pump is known, you can fix the required pipe pressure rating by referring Table 1.2.
- Once discharge of well is known, You can fix pipe diameter by referring Table 1.1 for the selected pipe pressure class.
- Once pipe is selected, you can fix the required pump specifications by referring Table 1.3 for pump head, pump outlet as per pipe diameter and discharge.
Now Vasani HDPE Coils are available with Quick Connect Joint
Traditionally PVC pipes are used for agricultural application because of its ease of installation and jointing method. Looking at the present scenario, Vasanis are happy to introduce the Vasani PE Coils with Quick Connect Joint. Vasani PE Coils with Quick Connect Joints will eliminate the onsite requirements of jointing machines and technical operators. A farmer can himself lay and connect the Vasani PE Coils and start watering the field. Quick Connect Joint involves a factory welded coupler with a rubber ring and holding clamp at one end and an insert piece at the other end. One just has to insert the plain portion of the coil into the coupler and bring the clamp to its home, the joint is complete. The product is available in pipe diameter ranging from 50mm to 110mm and in required length of 50, 100 or 200 meter based on pipe diameter.
